FB09G Bronze Base Rolling Bearings
- Bronze Base Rolling Bearings FB09G Bronze Base Rolling Bearings，CuSn8 tin bronze alloy as the material, the surface rolling diamond oil hole, played the role of fat storage, it has good fatigue strength and load-bearing capacity, corrosion resistance, abrasion resistance. Widely used in agricultural machinery, construction machinery, engineering machinery, high load low speed applications.
Technical ParametersMaterialMeritStandard bushing toleranceSize table Download
Technical Parameters
| Max.load | |
| Static load | 120 N/mm² |
| Dynamic load | 40 N/mm² |
| Max.speed | 2.5m/s |
| Max.PV | 2.8 N/mm²*m/s |
| Tensile strength | 450 N/mm² |
| Hardmess | HB>110 |
| Elongation | 40% |
| Max.temp | -100℃~+200℃ |
| Friction coef. | 0.08~0.25 |
| Thermal conductivity | 58W（m*k）-1 |
| Linear cofe. of thermal expansion | 18.5*10-6K-1 |
- High-density bronze molding or spherical oil bag, special synthetic oil hole interior surface to reduce wear and extend the use of time to do a good anti-corrosion features.
Merit
1. save a lot of copper, copper sets car system saves hours:
2. bushes, bearing compared to its light weight and low cost;
3. The friction surface can be processed in a variety of points there, pit, storing a grease, extended refueling time is five times that of copper sets;
4. The high load capacity, especially suitable for rough friction surface;
Products available: straight sets, thrust washers, flanged bushings, bearings, skateboards, steel sleeve assembly.
Standard bushing tolerance
| Standard Dia. | O.D.Size | Housing Bore | I.D.Size | Matching Shaft Diameter |
| 10~18 | +0.065 +0.030 | +0.018 0 |
+0.046 0 |
- 0.016 - 0.043 |
| 18~30 | +0.075 +0.035 | +0.021 0 |
+0.052 0 |
- 0.020 - 0.020 |
| 30~50 | +0.085 +0.045 | +0.025 0 |
+0.062 0 |
- 0.025 - 0.064 |
| 50~80 | +0.100 +0.055 | +0.030 0 |
+0.074 0 |
- 0.030 - 0.076 |
| 80~120 | +0.120 +0.070 | +0.035 0 |
+0.087 0 |
- 0.036 - 0.090 |
| 120~180 | +0.170 +0.100 | +0.400 0 |
+0.100 0 |
- 0.043 - 0.106 |
| 180~250 | +0.210 +0.130 | +0.046 0 |
+0.115 0 |
- 0.050 - 0.122 |
| 250~315 | +0.260 +0.170 | +0.052 0 |
+0.130 0 |
- 0.056 - 0.137 |
-
-
